Duplex ECCS Corrugated Steel Armored Fiber Optic Cable 8.2mm HDPE

Brand Name : AMD

Model Number : 2F-A2-8.2-PE-ECCS

Certification : ROHS

Place of Origin : CHINA

MOQ : 1000M

Price : Negociation

Payment Terms : T/T

Supply Ability : 100km per day

Delivery Time : According to the quantity

Packaging Details : 1000m, 500m per drum, without carton

Name : Corrugated Steel Armored Fiber Cable

Outer jacket : HDPE

Color : Black

Feature 1 : Water Blocking

Feature 2 : Rodent Resistant

Diameter : 8.2mm

Number Of Cores : 2 Cores

Armored tube Material : Steel Tape

Contact Now

Duplex ECCS Corrugated Steel Armored Fiber Optical Cable 8.2mm HDPE Rodent Resistant

Outdoor equipment

Corrugated steel armored fiber cables are suitable for outdoor use, because armored fiber cables are wear-resisting, and can take temperature fluctuations, then are often used for outdoor communication networks, industrial and infrastructure projects.

Cable Parameter:

Items		Specifications
Fiber Count		2
Tight-buffered Fiber	Dimension	0.9mm±0.05mm
	Material	PVC
	Color	Blue, Orange,
Inner Jacket	Dimension	3.8 mm±0.1mm
	Material	LSZH
	Color	Black
Outer Jacket	Dimension	8.2mm±0.3mm
	Material	HDPE
	Color	Black

Mechanical and Environmental Characteristics

Items	Unit	Specifications
Tension(Long Term)	N	500
Tension(Short Term)	N	800
Crush(Long Term)	N/10cm	300
Crush(Short Term)	N/10cm	1000
Min. Bend Radius(Dynamic)	mm	20D
Min. Bend Radius(Static)	mm	10D
Installation Temperature	℃	-40～+70
Operating Temperature	℃	-40～+70
Storage Temperature	℃	-40～+70

Cable can comply with following standards,

Torsion Resistance IEC 60794-1-2-E7

Tensile Force IEC 60794-1-2-E1,

Water penetration IEC 60794-1-2-F5 C,

Crush Resistance IEC 60794-1-2-E3,

UV Resistance ASTM G154-16, Exposure : 720 hrs, IL≤0.05dB 6 Cycles

Anti-Rodent Cable should be rodent bite-proof

Kink Resistance IEC 60794-1-2-E10, 10xD,
